Smd Led 2835 1w Full Spectrum
Lub Hwj Chim Loj: {{0}}.2W, 0.5W, 1W, 1.5W, 2W Fais Fab Dissipation Muaj.
Forward voltage: 3V, 6V, 9V, 18V, 36V.
Tom ntej: 30mA, 60mA, 100mA, 150mA, 350mA.
Xim Rendering Index: Ra80, Ra90, Ra95, Ra98, 99Ra.
High Lub Teeb Ua Haujlwm: 220LM / W muaj.
Xa kev nug
Khoom Taw qhia
smd coj 2835 1w puv spectrum
Khoom nta ntawm smd coj 2835 1w tag nrho spectrum:
Lub Hwj Chim Loj: {{0}}.2W, 0.5W, 1W, 1.5W, 2W Fais Fab Dissipation Muaj.
Forward voltage: 3V, 6V, 9V, 18V, 36V.
Tom ntej: 30mA, 60mA, 100mA, 150mA, 350mA.
Xim Rendering Index: Ra80, Ra90, Ra95, Ra98, 99Ra.
High Lub Teeb Ua Haujlwm: 220LM / W muaj.
CCT Range: 1600-1800K, 1800-2000K, 2000-2200K, 2200-2400K, 3000-10000K.
Lub teeb xim: Liab, Ntsuab, Xiav, Daj, UV, IR ...
Full Spectrum 380-850nm.
Specifications:
| 2835 LED SERIES Specification | ||||||
| Khoom npe | Xim Xim | CCT / wavelength | Qhov hluav taws xob | Tam sim no | Lumen | Lus hais |
| 0.2W 2835 LED | Kub daj | 1800-2000K | 2.8-3.4V | 60mA ua | 24-30LM | SIB 80,90 |
| 0.2W 2835 LED | Dawb | 3000-6500K | 2.8-3.4V | 60mA ua | 24-34LM | CRI80,90,96 ntxiv |
| 0.5W 2835 LED | Dawb | 3000-6500K | 2.8-3.4V | 150 mA | 55-75LM | CRI80,90,96 ntxiv |
| 1W 2835 LED | Dawb | 3000-6500K | 6/9/18/36V | 150/100/50/30mA | 90-150LM | High Voltage Series |
| 2835 UV LED | UV | 365-410nm | 3/6/9V | 60/150/175/100mA | / | 0.2W, 0.5W, 1W |
| 2835 Xiav LED | Xiav | 440-470nm | 3/6/9V | 60/150/175/100mA | 4-20LM | 0.2W, 0.5W, 1W |
| 2835 Ntsuab LED | Ntsuab | 520-530nm | 3/6/9V | 60/150/175/100mA | 18-80LM | 0.2W, 0.5W, 1W |
| 2835 Amber LED | Yellow / Amber | 590-610nm | 2/4/6V | 60/150/175/100mA | 6-20LM | 0.2W, 0.5W, 1W |
| 2835 Liab LED | Liab | 620-630nm | 2/4/6V | 60/150/175/100mA | 8-30LM | 0.2W, 0.5W, 1W |
| 2835 Sib | Liab Far | 660-665nm | 2/4/6V | 60/150/175/100mA | 3-12LM | 0.2W, 0.5W, 1W |
| 2835 IR LED | IR | 730-750nm | 2/4/6V | 60/150/175/100mA | / | 0.2W, 0.5W, 1W |
| 2835 IR LED | IR | 850nm ua | 2/4/6V | 60/150/175/100mA | / | 0.2W, 0.5W, 1W |
| 2835 PC Blue | Phosphor Blue | 450-470nm | 3/6/9V | 60/150/175/100mA | 6-30LM | 0.2W,0.5W,1W Customized WD, WP |
| 2835 PC Green | Phosphor Ntsuab | 510-530nm | 3/6/9V | 60/150/175/100mA | 18-120LM | |
| 2835 PC Xim | Phosphor Amber / Liab | 600-630nm | 3/6/9V | 60/150/175/100mA | 10-60LM | |
