Football Field Lighting Design Guide: Cov qauv, Layouts, Fixture Selection, thiab Chaw tsim tshuaj paus tswv yim

Dab tsi yog Football Field Lighting thiab Vim Li Cas Nws Tseem Ceeb

Txhais:
Lub teeb pom kev ncaws pob yog hais txog lub teeb pom kev zoo teeb pom kev zoo uas tau teeb tsa thiab nyob ib puag ncig ntawm qhov chaw ncaws pob kom ua tau raws li qhov xav tau ntawm kev sib tw, kev cob qhia, tshaj tawm, thiab cov neeg saib. Nws tsis yog "teeb ​​pom kev ntawm lub tshav pob" - nws ua kom cov players pom tau meej lub pob thiab cov phooj ywg, cov neeg saib xyuas tuaj yeem hu tau raug, thiab cov neeg saib (xws li cov neeg saib TV) muaj kev pom kev zoo los ntawm kev tswj cov tsis xws li teeb pom kev zoo, qhov sib xws, qhov ntsuas qhov muag pom, thiab xim kub.

Lub luag haujlwm ntawm cov teeb pom kev zoo hauv kev pom, kev nyab xeeb, thiab kev ua haujlwm

Lub teeb pom kev zoo tshem tawm qhov tsaus ntuj thiab ci ntsa iab, pab cov neeg ua si taug qab lub pob nrawm nrawm thiab txo qis kev sib tsoo lossis kev raug mob los ntawm qhov tsis pom kev. Rau kev sib tw ncaws pob lossis cov hluas, lub teeb txaus kuj txo cov xwm txheej xws li ntog thiab pob tw. Nyob rau tib lub sijhawm, ib puag ncig teeb pom kev ruaj khov tiv thaiv kev tsis ncaj ncees vim yog qhov ntxoov ntxoo, yog li kev txhim kho kev ua haujlwm thiab kev ua kom zoo.

Qhov sib txawv ntawm thaj chaw cob qhia, thaj chaw tsev kawm ntawv, thiab chaw ntau pob
Cov teeb pom kev zoo yuav tsum sib txawv heev rau cov qib sib txawv. Cov lus hauv qab no qhia txog kev sib piv ib txwm:

Vim li cas LED dej nyab teeb feem ntau siv
Piv rau cov khoom siv hlau halide lossis halogen teeb, LED dej nyab teeb muaj txiaj ntsig zoo rau kev teeb pom kev ncaws pob:

• Kev txuag hluav taws xob- 60% -70% qis zog siv rau tib lub teeb pom kev zoo.
• Instant on/off thiab dimming- tsis muaj lub sijhawm sov so, txhawb ntau hom (kev cob qhia, sib tw, ua kom sov).
• Precise optics- lo ntsiab muag tsim cov duab plaub lossis asymmetric teeb pom kev zoo, txo lub teeb tawg mus rau sawv lossis saum ntuj.
• Lub neej ntev thiab kev saib xyuas qis- tshaj 50,000 teev, txo qhov zaus ntawm kev hloov luminaires ntawm qhov siab.
• Flicker-dawb- nrog cov tsav tsheb zoo, ua tau raws li lub koob yees duab ceev ceev.

Cov yam ntxwv no tau ua rau LED dej nyab lub teeb qhov kev xaiv rau txhua yam los ntawm cov chaw ua si hauv tsev kawm mus rau qhov chaw ncaws pob ntiaj teb.

Football Field Lighting Standards Koj Yuav Tsum Paub

Lux Level Requirements rau ntau hom teb

Ib qho ntawm cov kev ntsuas tseem ceeb yogkab rov tav illuminance- lub luminous flux ntom tau txais rau hauv av. CIE thiab lub teb chaws teeb pom kev ua kis las cov qauv (piv txwv li, IESNA, GB, JGJ 153 hauv Suav teb, EN 12193 hauv Tebchaws Europe) feem ntau tau teeb tsa cov nqi pom zoo raws li cov chav kawm. Hom qeb:

Nco tseg:Ib txwm xa mus rau cov lej hauv zos (xws li Tuam Tshoj JGJ 153, Europe's EN 12193). Cov nqi saum toj no yog cov ntaub ntawv siv tau.

Uniformity thiab Glare Control

Kev tsis sib xwspiav qhia tias lub teeb pom kev zoo npaum li cas faib thoob plaws hauv thaj teb. Ob qho piv txwv:

• U1 (min / max)- ratio ntawm darkest mus brightest point. Feem ntau xav tau U1 Ntau dua lossis sib npaug rau 0.4–0.6.
• U2 (min / nruab nrab)- qhov taw qhia nruj dua kom tsis txhob muaj thaj tsam loj ntawm lub teeb / tsaus. Feem ntau xav tau U2 Ntau dua lossis sib npaug rau 0.6–0.8.

Piv txwv li: ib daim teb nrog 500 lx nruab nrab tab sis U2=0.4 muaj thaj chaw qis dua 200 lx - cov neeg ua si yuav "poob" pob ib ntus thaum sprinting, nce yuam kev.

Glare tswjraug soj ntsuam nrogGlare ntsuas (GR):

• GR Tsawg dua lossis sib npaug li 30: ze li qhov tsis pom kev, haum rau kev sib tw tshaj lij thiab tshaj tawm hauv TV.
• GR 30–40: pom tau me ntsis glare, rau amateur lossis kev cob qhia.
• GR> 40: pom tseeb qhov muag pom, tuaj yeem cuam tshuam cov neeg ua si, tsis pom zoo rau kev sib tw ua haujlwm.

Txoj kev txo qis qis: siv LED dej nyab teeb nrog visors lossis lo ntsiab muag; teem lub kaum ntse ntse kom zoo (tsis txhob pom txoj kab ncaj nraim); siv ntau tus ncej nrog symmetric layout.

Xim kub thiab CRI cov lus pom zoo

Correlated Xim Kub (CCT): xav5000K – 6000K(txias dawb).

Qhov no yog ze rau nruab hnub nrig (5500K thaum tav su), ua rau muaj kev ceeb toom thiab qhov sib txawv, thiab ua tau raws li HD TV xim sib npaug. Hauv qab 4000K zoo li dim, saum 6500K yuav zoo li xiav thiab ua rau qhov muag qaug zog.

Xim Rendering Index (CRI) :

• Kev cob qhia / tsev kawm ntawv teb: CRI Ntau dua lossis sib npaug rau 70 (paub xim paub)
• Amateur ntais ntawv: CRI Ntau dua lossis sib npaug rau 80 (kwv yees cov khoom siv, thaj tsam thaj tsam)
• Kev tshaj tawm / TV tshaj tawm: CRI ntau dua lossis sib npaug rau 90, thiab pom zooR9 (liab rendering) Ntau dua los yog sib npaug rau 20los xyuas kom meej cov tawv nqaij tones, liab tsho, thiab lwm yam.

High CRI tsis tsuas yog txhim kho kev pom tab sis kuj tseem pab cov neeg txiav txim txiav txim siab offside, fouls, thiab lwm yam (piv txwv li, qhov sib piv ntawm khau raj thiab nyom).

Standard piav nrog Piv txwv

Coj ib5,000-lub rooj sib tw hauv cheeb tsam chaw ua sitsim los kom tau raws li kev tshaj tawm hauv TV hauv zos (Class IV) thaum ua tau zoo nrog kev sib tw ua si (Class II):

• Illuminance tsim: 1500 lx kab rov tav (lub ntsiab lub koob yees duab kev taw qhia), 1200 lx (auxiliary); kev cob qhia hom dimmable rau 300 lx.
• Kev tsis sib xws: U2 Ntau dua los yog sib npaug rau 0.7, kom tsis txhob muaj qhov pom tseeb ntawm cov duab ntxoov ntxoo ntawm qhov kov lossis lub voj voog nruab nrab.
• Glare: GR Tsawg dua los yog sib npaug li 30, siv plaub-kab ncej, aiming 15℃-20℃tawm ntawm kab nruab nrab.
• Xim: 5700K, CRI ntau dua lossis sib npaug rau 90, R9=25.

Nrog rau ntau hom kev tswj (kev sib tw / kev cob qhia / sov-up / tu), nws ua tau raws li kev tshaj tawm zoo thaum txuag hluav taws xob thaum ua haujlwm txhua hnub. Kev lees txais zaum kawg yuav tsum tau ntsuas ntawm qhov chaw thiab hloov kho rau txoj haujlwm ncej thiab lumen depreciation.

Cov ntsiab lus:Ua raws li cov qauv tsis yog tsuas yog "tso cov ncej thiab ncav cuag lux" - nws sib npaug cov kev xav tau ntawm cov qib sib txawv, tus nqi, kev siv hluav taws xob, thiab kev paub pom. Tom ntej no, peb yuav pom yuav ua li cas muab cov qauv no rau hauv kev xyaum nroglayout tsim.

Yuav Ua Li Cas Npaj Lub Teeb Pom Kev Football Field

Ncej Qhov siab thiab Ncej qhov chaw

Ncej qhov siab thiab qhov chaw txiav txim siab beam pov, kev tiv thaiv, thiab glare tswj. Cov layouts:

Cov ntsiab cai xaiv:

• Ncej qhov siab ≈ teb ntev / 4 txog / 6 (piv txwv li, rau 100 m ntev → 18–25 m).
• Ncej yuav tsum yog tsawg kawg 1.5 m sab nraum lub touchline thiab tsis thaiv lub koob yees duab views.
• Nrogasymmetric faibLED luminaires, koj tuaj yeem txo tus ncej qhov siab thiab ua kom pom lub kaum ntse ntse.

Fixture Quantity thiab Spacing

Kwv yees tag nrho cov luminaire suav yuav tsum muaj tag nrho cov luminous flux xav tau, lumen tso zis rau ib lub luminaire, siv qhov tseem ceeb, thiab kev saib xyuas. Cov kauj ruam uas pom zoo:

• Txiav txim siab lub hom phiaj nruab nrab illuminance(piv txwv li, kev cob qhia 300 lx, phim 750 lx).
• Xam tag nrho cov lumen xav tau:

Tag nrho lumens (lm)=Cheeb Tsam (m²) × lub hom phiaj illuminance (lx) ÷ utilization factor ÷ txij nkawm

Kev siv yam tseem ceeb (UF): LED kev ua si luminaires feem ntau 0.6-0.8 (nyob ntawm seb qhov ua tau zoo ntawm optics).

Maintenance factor (MF): noj 0.7-0.8 rau plua plav thiab lumen depreciation.

• Xaiv tus naj npawb ntawm tus ncej- lub kaum sab xis layout: 8-20 luminaires ib tug ncej; sab layout: 5-12 ib sab.
• Faib ib cheeb tsam- Txhua lub luminaire teeb rau thaj tsam kab sib chaws, zam kev sib tshooj ntau dhau lossis tsaus nti.

Daim ntawv teev npe (rau tus qauv 11-a-sab suab 105m × 68m) :

Cov lej tiag tiag nyob ntawm lub kaum ntse ntse thiab cov ntaub ntawv IES - yuav tsum muaj qhov kev sim kho qhov muag.

Beam Angle thiab Aiming Direction

Beam lub kaum sab xistxiav txim siab npaum li cas lub teeb kis:

• Nqaim beam (5℃-15 degree) : pov tseg ntev, piv txwv li, kaum ncej teeb pom kev deb ib nrab.
• Nruab nrab beam (15℃-30 degree) : wider coverage, for the center circle or side layout.
• Txoj kab dav dav (30℃-60 degree) : close-field filling light or stand areas.

Cov tswv yim pom zoo: sib xyaw cov kab nqaim thiab nruab nrab ntawm tib tus ncej kom meej zoning - nqaim kab teeb tsom ntawm lub voj voog nruab nrab, kab nruab nrab npog thaj tsam ntug ntug, dav kab teeb pom kev ze ze.

Lub hom phiajyuav tsum tsis txhob glare thiab xyuas kom meej uniformity:

• Lub aiming kev taw qhia yuav tsum muaj ibkab rov tav offset ntawm 15℃-30 degreelos ntawm txoj kab nruab nrab (ntev axis) los tiv thaiv lub teeb nkag mus rau cov neeg ua si kab kab rov tav pom.
• Vertical aiming angle ( qaij) feem ntau yog 30℃-60℃(lub taub hau taw rau hauv qab). Cov ces kaum loj dua muab cov teeb pom kev zoo dua hauv av tab sis tuaj yeem ua rau pom qhov kaj - siv cov visors lossis lens txiav kom zoo.

On-site aiming checklist(tom qab installation):

• Xyuas txhua lub luminaire lub hom phiaj tiv thaiv kev kos duab (siv laser pointer).
• Ntsuas av illuminance faib, paub meej tias U2 Ntau dua lossis sib npaug rau 0.6.
• Ntsuas qhov ci ntsa iab los ntawm ntau txoj haujlwm (tshwj xeeb yog kaum-kick me ntsis thiab qhov chaw nplua).
• Yog tias muaj qhov tsaus ntuj, kho cov kab rov tav / ntsug ntawm cov luminaires nyob ze, lossis ntxiv luminaires.

Tswv yim:High-quality LED luminaires yuav tsum muajadjustable bracketsthiablub kaum ntse ntserau meej aiming. Rau qhov chaw tshaj tawm hauv TV, xav txogdual-ring aiming( taw tes lub teeb thaj ua rau thaj rau ob lub koob yees duab tseem ceeb).

Yuav Ua Li Cas Xaiv Txoj Cai LED Dej nyab lub teeb rau Football Field

Kev xaiv Wattage los ntawm Teb Loj

Tsis muaj cov qauv tsim nyog, tab sis cov lus hauv qab no muab cov ntaub ntawv siv los ntawm qib teb thiab qhov loj me.

Cov lus qhia xaiv:Nyiamdim-rau-npaj tsav tsheb- Cov khoom siv tib yam tuaj yeem hloov kho rau kev cob qhia, kev sib tw, thiab kev tshaj tawm cov qauv, zam kev sib tw peev.

Lumens thiab Lighting Distribution

Wattage (W) tsis yog qhov taw qhia qhov ci ncaj qha; saibluminous flux (lumen lm)thiabKev ua tau zoo (lm / W).

• Kev cob qhia / tsev kawm ntawv teb130-150 lm / W pom zoo, tag nrho flux kwv yees li 150,000-300,000 lm.
• Kev tshaj tawm / TV tshaj tawm : ≥150 lm/W recommended; premium products reach 170–200 lm/W, total flux >8,000,000 lm.

Lub teeb faib (photometric nkhaus)yog qhov tseem ceeb rau kev xaiv:

Cov lus qhia xaiv:

• Rau kaum layout, xaivasymmetric / batwing lo ntsiab muagyog li lub teeb yog qhia feem ntau sab hauv, tsis yog mus rau sawv los yog ntuj.
• Rau sab layout, sivsymmetric wide beamslos yogduab plaubkom tsis txhob muaj qhov tsaus ntuj nyob ze-sideline.

IP ntsuam xyuas, Durability, thiab tshav kub dissipation

Football field luminaires raug tawm sab nraum zoov - los nag, cua daj cua dub, kub kub, khov.

• Kev ntsuas IP: xavIP66 los yog siab dua(plua plav nruj, tiv thaiv lub dav hlau dej muaj zog). IP65 yog qhov tshwm sim tab sis nws yuav ua tsis tiav thaum los nag hnyav.
• IK qhov kev ntsuam xyuas: vaj tse thiab lens yuav tsum ncav cuagIK08 los yog siab dua(5J cuam tshuam, sib npaug rau 1.7kg poob ntawm 30cm).
• Thaum tshav kub kub dissipation tsim :

Sivfin-type heatsinkslos yogtuag-cast aluminium vaj tsekom nce qhov chaw.

Kev ua kom txias txias (kiv cua) tsis pom zoo rau cov chaw ua si sab nraum zoov - lawv khaws cov plua plav, ua tsis tiav, thiab tsim suab nrov.

Xyuas kom muaj kev ua haujlwm kub tsawg dua lossis sib npaug li 85 degree; lub neej thiab kev tu lumen raug cuam tshuam ncaj qha los ntawm tshav kub.

• Daim ntawv txheeb xyuas Durability :

Lub tsev yog high-density die-cast aluminium nrog anti-corrosion txheej (C5-M los yog siab dua rau cov ntug dej hiav txwv / high-humidity).

Cov ntsaws ruaj ruaj yog silicone, UV-resistant.

Lens yog tempered iav los yog optical PC, UV ruaj khov, tsis daj.

Kev tiv thaiv hluav taws xob ntau dua lossis sib npaug li 10kV (20kV pom zoo nyob rau hauv cheeb tsam xob laim).

Tib -Module vs Multi-Module Fixtures

Niaj hnub nimno LED kev ua si luminaires tuaj rau hauvsingle-module (ib lub teeb ci)los yogmulti-module (ntau yam ywj pheej modules)cov qauv.

Cov lus qhia xaiv:

• TV tshaj tawm qib: nyiamsingle-module lossis high-integration rectangular tisluminaires - ib yam tsis muaj seams.
• Kev cob qhia / tsev kawm ntawv teb : multi-moduleluminaires muab tus nqi zoo dua thiab hloov kho tau yooj yim.

Cov khoom sib piv (rau 105m × 68m TV tshaj tawm hauv tebchaws):

Cov lus qhia zaum kawg:Kev siv nyiaj tsawg → multi-module; nrhiav kev txuag hluav taws xob mus sij hawm ntev thiab kev tshaj tawm zoo → ib leeg-module. Txawm li cas los xij, ib txwm nug rauIES cov ntaub ntawv photometricthiab khiav Dialux lossis AGI32 simulation.

Kev txhim kho tshiab vs Retrofit: Cov tshuaj twg haum rau koj zoo dua?

Thaum twg los xaiv lub teeb pom kev zoo tshiab

Kev txhim kho tshiab txhais tau tias tsim cov ncej, lub zog faib hluav taws xob, kev tswj hwm, thiab cov teeb pom kev zoo los ntawm kos. Xaivtshiabhauv cov xwm txheej no:

• Cov teb uas twb muaj lawm tsis muaj teeb pom kev zoo- Piv txwv li, lub tsev kawm ntawv tshiab, kev teeb tsa thawj zaug rau thaj chaw hauv zej zog.
• Cov ncej lossis hluav taws xob muaj hnub nyoog hnyav heev- corrosion, xoob foundations, qub cables tsis tuaj yeem nqa LED.
• Kev nce qib teb- Piv txwv li, kev cob qhia rau kev tshaj tawm hauv TV, yuav tsum muaj ntau tus luminaires, txoj haujlwm, ncej qhov siab, lossis lub zog muaj peev xwm.
• Layout yog inherently tsis zoo- Piv txwv li, ib sab layout tsis tuaj yeem ua tau raws li qhov sib xws / glare txawm tias tom qab kev ua kom zoo dua.

Qhov zoo ntawm qhov system tshiab:

• Ua raws li cov qauv tam sim no, yav tom ntej pov thawj rau 5-10 xyoo.
• Lub tshuab hluav taws xob tsim los rau cov yam ntxwv LED (dimming, ntse tswj) - tsis muaj teeb meem kev sib raug zoo.
• Ncej txoj haujlwm, qhov siab, kev tiv thaiv xob laim tuaj yeem ua kom zoo dua - kev saib xyuas lub sijhawm ntev.

Qhov tsis zoo:

• Kev nqis peev ntau dua (ncej, cabling, kev ua haujlwm hauv pej xeem).
• Lub sijhawm tsim kho ntev dua (cov hauv paus, txhim kho ncej, cov kav dej - feem ntau 2-4 lub lis piam).

Yuav Ua Li Cas Hloov Hlau Halide Teeb nrog LED

Retrofit txhais tau hais tias khaws cov ncej uas twb muaj lawm thiab ib feem ntawm cov xaim, tsuas yog hloov cov hlau halide luminaires nrog LED. Cov kauj ruam:

1.Qhov chaw soj ntsuam

• Sau cov ncej uas twb muaj lawm qhov siab, txoj hauj lwm, lub peev xwm thauj khoom (LED units feem ntau sib dua, tab sis kos lub bracket haum).
• Ntsuas cov teeb pom kev zoo uas twb muaj lawm, txheeb xyuas qhov tsaus nti thiab teeb meem glare.
• Txheeb xyuas lub ntsuas hluav taws xob thiab lub peev xwm tawg (LED yog lub zog qis dua, feem ntau tsis xav tau hloov kho dua tshiab, tab sis txheeb xyuas qhov ntsuas hluav taws xob poob thiab tiv thaiv hluav taws xob).

2. Rov qab kho qhov muag xam

• MH teeb yog omnidirectional; LED yog directional nrog meej optics.
• Tsis txhob ua qhov ncaj qha "W rau W" hloov. Muab qhov xav tau LED lumens los ntawm lub hom phiaj illuminance, tom qab ntawd xaiv cov kaum sab xis.
• Kev hloov kho qhov sib piv: 1000W MH → 300-500W LED (sib npaug lossis siab dua illuminance).

3.Lluminaire rau cov ncej uas twb muaj lawm adaptation

• Txheeb xyuas qhov sib txuas ntawm qhov sib txuas thiab qhov kev hloov kho qhov sib npaug ntawm tus ncej qub.
• Yog tias tus ncej saum toj kawg nkaus muaj lub kaum sab xis saum toj lossis lub phaj puag ncig, cov phaj hloov pauv yuav xav tau.

4. Hluav taws xob retrofit

• Tshem tawm cov ballasts, ignitors, capacitor banks (tshwj xeeb rau MH).
• Nruab LED tsav tsheb, ntxiv surge tiv thaiv cov cuab yeej (SPD, Ntau dua lossis sib npaug li 10kV).
• Yog tias yuav tsum tau dimming, ntxiv 0-10V lossis DALI teeb liab xov hlau (los yog xaiv wireless tswj yog tias tsis muaj teeb liab nyob ntawm tej).

5.Installation thiab aiming

• Hloov luminaires ib qho los ntawm ib qho, tsom raws li kev suav tshiab.
• Fais fab mus, ntsuas illuminance thiab uniformity, fine-tune kaum raws li xav tau.

Case Study:Ib lub koom haum amateur muaj plaub 15m ncej, txhua tus muaj plaub 1000W MH luminaires - tag nrho 16kW, nruab nrab illuminance ~ 250 lx, U2=0.45, GR≈45. Retrofit: rau 600W LED ib tug ncej (tag nrho 14.4kW - me ntsis tso zis), siv asymmetric 40℃× 80℃optics, re-optimised aiming. Tom qab retrofit: illuminance 450 lx, U2=0.68, GR=28, hluav taws xob nqi txo ~ 65%, tsis muaj kev sov so tos.

Common Retrofit Risks thiab Nqis

Tus nqi siv (rau 11-a-sab, 48 MH luminaires → LED) :

Xaus:Yog tias cov ncej uas twb muaj lawm yog qhov tsim nyog siab, muab tso rau zoo, thiab cov khoom siv hluav taws xob tsawg dua lossis sib npaug li 10 xyoo, kev rov ua dua yuav txuag tau 40% -60% ntawm kev nqis peev thiab tuaj yeem ua tiav sai (3-7 hnub). Yog tias txoj haujlwm ncej tsis raug lossis qhov siab tsis txaus, mus rau qhov tshiab - txwv tsis pub koj "txuag me ntsis tab sis tseem tsis ua raws".

Feem ntau yuam kev hauv Football Field Lighting Projects

Tshaj - teeb pom kev zoo lossis Hauv qab - teeb pom kev zoo

Cov tsos mob:

• Tshaj teeb pom kev zoo: deb tshaj tus qauv (piv txwv li, 1500 lx ntawm qhov chaw cob qhia) - pov tseg lub zog, ua rau pom qhov muag loj, neeg ua si qaug zog lossis qhov muag tsis pom ib ntus.
• Lub teeb pom kev zoo: tsuas yog 100-200 lx siv rau kev sib tw ua si - cov neeg ua si tawm tsam taug qab lub pob, ntau tus kws txiav txim siab yuam kev, cov neeg saib tsis zoo.

Root ua rau:
Qhov muag tsis pom kev ntawm "ci ntsa iab yog qhov zoo", lossis txo tus nqi los ntawm kev txo cov luminaire suav / siv cov khoom siv hluav taws xob tsawg. Tsis tas li ntawd tsis nco qab txij nkawm - tom qab ib xyoos, lumen depreciation poob illuminance ho.

Kev daws:

• Ua raws li tus qauv rau cov chav kawm, thiab ntxiv 10% -20% paj rau lumen depreciation.
• Siv Dialux lossis AGI32 simulations - txheeb xyuas qhov sib xws nrog cov xim tsis tseeb, tsis yog qhov nruab nrab qhov tseem ceeb.
• Tom qab kev teeb tsa, ntsuas thiab kho kom lub teeb pom kev hauv lub hom phiaj.
• Siv cov dimmable LEDs - yog tias ci dhau lawm, tsuas yog txo lub zog.

Tsis zoo Beam Control

Cov tsos mob:
Lub teeb ci tawm sab nraum lub tshav - mus rau qhov chaw sawv, cov tsev nyob sib ze, lossis hmo ntuj (lub teeb muaj kuab paug); los yog teb muaj "zebra" kab txaij ntawm lub teeb thiab tsaus, ua rau pom kev cuam tshuam thaum cov players khiav.

Root ua rau:

• Siv symmetric (round) optics nrog cov ncej tsis zoo - tsis tuaj yeem npog cov duab plaub zoo.
• Tsis quav ntsej cov visors lossis cov khoom siv tiv thaiv glare.
• Aiming ces kaum yog random, tsis zoned.

Kev daws:

• Rau kaum layout, ua ntejasymmetric / rectangular opticslos yog LED luminaires nrog rau lub ntsej muag - ua rau sab ntev ntawm lub nqaj ua raws li kab pheeb ces kaum.
• Muab lub hom phiaj rau txhua qhov luminaire ntawm txhua tus ncej (piv txwv li, Ncej A: 1# aim ze ze, 2# aim deb goalpost, 3# aim center circle…).
• Ntawm qhov chaw, siv inclinometers thiab laser pointers los txheeb xyuas cov kab rov tav / ntsug ntawm txhua lub luminaire.
• Nruabdaim thaivlos yogglare visorsntawm cov ncej kom txiav lub teeb khiav mus rau sab nraud lossis lub koob yees duab.

Ignoring Maintenance Access

Cov tsos mob:
Tom qab kev teeb tsa, cov neeg saib xyuas tsis tuaj yeem ncav cuag lub teeb pom kev zoo - cov ncej tsis muaj tus ntaiv lossis cov chaw pabcuam, xav tau cov tsheb thauj khoom kim kim los hloov ib lub teeb. Lenses yeej tsis ntxuav, poob 30% ntawm cov zis. Tus neeg tsav tsheb tsis ua haujlwm thiab tag nrho lub tsev tau muab pov tseg vim nws tsis tuaj yeem muab kev pabcuam.

Root ua rau:
Design phase only considered lighting effect, ignoring serviceability. Especially when pole height >15 m thiab tsis muaj kev nkag mus mus tas li - txhua qhov siab qhov siab hu tawm yog kim.

Kev daws:

• For poles >12 m ,xavntaiv + kev ruaj ntseg tawbthiab akev pabcuam platformnyob rau sab saum toj (tsawg kawg qhov chaw rau ib tus neeg ua haujlwm).
• Sivqis-hom ncej(lub nplhaib qis rau hauv av) los yoghinged ncej(tuaj yeem qaij nqes) - txo qis txij nkawm nyuaj.
• Xyuas kom cov tsav tsheb yogkub-swappablelos yog modular, yuav tsum tsis muaj vuam lossis txiav cov cuab yeej los hloov.
• Tsim kom muaj lub sijhawm tu ib txwm (txhua 6-12 lub hlis nrog cov tshuaj ntxuav me me) thiab sau cov lumen depreciation.

Xaiv Teeb Tsuas yog los ntawm Wattage

Cov tsos mob:
Kev yuav khoom tsuas yog "yuav muaj pes tsawg watts", tsis quav ntsej txog kev ua tau zoo, CCT, CRI, kev faib nkhaus, IP ntsuas. Qhov tshwm sim: 800W teeb nrog tsuas yog 100 lm / W - dimmer tshaj 500W los ntawm lub npe nrov; los yog 6500K ua lub teb xiav-dawb, players yws ntawm hnyav.

Root ua rau:
Tsis muaj kev paub txog teeb pom kev zoo, lossis yuam kev los ntawm tus nqi qis / qis-wattage thov ("kev txuag hluav taws xob"). Qee cov tuam txhab lag luam ua tsis raws cai; tus neeg yuav khoom tsis thov IES cov ntaub ntawv lossis cov ntaub ntawv xeem thib peb.

Kev daws:

• Tsim kom muaj ibkey specification checklist(yam tsawg kawg yuav tsum):

• Nug rauCov ntaub ntawv qhia txog kev ntsuas photometric thib peb, tsis yog cov ntaub ntawv lag luam hauv tsev.
• Uakev sim ntawm qhov chaw- yuav 2-4 units, nruab rau ntawm cov ncej uas twb muaj lawm, ntsuas illuminance thiab glare, ces txiav txim siab ntau.

Cov ntsiab lus:Kev zam plaub qhov yuam kev no tiv thaiv 80% ntawm kev rov ua haujlwm thiab tsis txaus siab. Lub luminaire zoo ≠ tsuas yog watts. Lub kaw lus zoo=illuminance raug + beam tswj + kev saib xyuas yooj yim.

Yuav Ua Li Cas Nug Lub Chaw Tsim Khoom Football Field Lighting

Muaj peev xwm OEM / ODM

Vim li cas nws tseem ceeb:
Cov chaw sib txawv yuav xav tau kev cai brackets, kev faib lub lens, tswj cov txheej txheem, lossis txawm tias cov xim vaj tse. Cov neeg tsim khoom nrog OEM (tsim rau koj lub npe) lossis ODM (tsim thiab tsim) muaj peev xwm tuaj yeem tsim cov khoom lag luam rau koj cov duab kos, thaum cov khoom txheem yuav tsis haum cov ncej qub lossis cov txheej txheem tshwj xeeb.

Cov lus nug:

• Koj puas tuaj yeem kho cov kab tsis-tus qauv (piv txwv li, qub ncej qhov qauv offset los yog crossarms txawv txawv)?
• Koj puas tuaj yeem muab kev cai asymmetric optics (piv txwv li, 15℃× 45 degree, 20℃× 70℃rectangular beams)?
• Koj puas lees txais MOQ qis rau customizations (piv txwv li, 24 units lossis tsawg dua)?
• Puas muaj tus nqi engineering rau kev cai optics? Koj puas muaj lub tsev qiv ntawv IES npaj rau kev siv ceev?

Cov lus qhia ntsuas:
Nyiam cov tuam txhab lag luam uas muaj lawv lub lens molding qhov chaw - lawv tuaj yeem ua tiav cov khoom me me hauv 7-15 hnub yam tsis muaj tus nqi siab.

Ntawv pov thawj thiab kuaj

Vim li cas nws tseem ceeb:
Cov luminaires uas tsis tau lees paub yuav ua rau muaj kev phom sij rau kev nyab xeeb (hluav taws xob, hluav taws xob) thiab tsis tuaj yeem dhau qhov kev lees txais lossis tsim nyog rau tsoomfwv cov nyiaj pab. Lub teeb pom kev ncaws pob yuav tsum ua tau raws li kev nyab xeeb hluav taws xob hauv zos thiab cov qauv teeb pom kev ua kis las.

Cov ntawv pov thawj tseem ceeb & kev xeem:

Cov lus nug:

• Koj puas tuaj yeem muab cov ntawv luam theej ntawm daim ntawv pov thawj saum toj no (tsis tas sijhawm)?
• Koj puas muab daim ntawv pov thawj luminaire tag nrho (tsis yog LED module xwb)?
• Koj puas tau ua qhov ntsuas cua qhov (cua tsis kam)? Cov ntaub ntawv rau typhoon-theem cua (12+)?

Photometric Report

Vim li cas nws tseem ceeb:
Daim ntawv tshaj tawm photometric tsuas yog lub hauv paus los txiav txim qhov ua tau zoo tiag tiag. Cov tuam txhab lag luam tsis zoo tuaj yeem nyiag cov ntaub ntawv IES lossis ua tsis tau raws li qhov ua tau zoo. Daim ntawv tshaj tawm yuav tsum muaj xws li: kev faib nkhaus (polar/rectangular), isocandela daim duab, luminous flux, kev ua tau zoo (lm/W), beam angle (ib nrab-peak intensity), thiab cov ntaub ntawv ntsig txog glare.

Yuav ua li cas rau hauv daim ntawv qhia:

• Kev tawm lab: yuav tsum yoglwm tus neeg ywj pheej(piv txwv li, TÜV, UL, SGS, NVLAP-accredited), tsis nyob hauv tsev.
• Qhia tus lej thiab hnub tim - traceable, feem ntau siv tau 2-3 xyoos.
• Kev ntsuas deb - feem ntau 10-30 m, ntau dua li qhov loj ntawm lub teeb ci.
• Kev ntsuas lub sijhawm luv luv tsawg dua lossis sib npaug li 2.5℃(siab precision).
• Muajcov ntaub ntawv photometric kiag li(tuaj yeem xa mus rau Dialux), tsis yog cov duab xwb.

Cov lus nug:

• Thov muab covIES lossis LDT cov ntaub ntawvrau lub caij nyoog qauv (rau peb simulate).
• Puas yog lub zog tshaj tawm thiab tus neeg tsav tsheb tam sim no phim cov khoom xa tuaj?
• Puas txawv beam angle variants txhua tus muaj lawv tus kheej daim ntawv qhia?
• Koj puas muab cov ntaub ntawv photometric rau ntau CCTs (piv txwv li, 5000K, 5700K)?

Warranty thiab Lead Time

Vim li cas nws tseem ceeb:
Txawm hais tias LEDs muaj lub neej ntev, kev tsav tsheb, kev tiv thaiv kev tiv thaiv, thiab lwm yam, tuaj yeem ua tsis tau thaum ntxov. Cov ntsiab lus lees paub meej thiab lub sijhawm ua haujlwm txhim khu kev qha ncaj qha cuam tshuam rau lub sijhawm ua haujlwm thiab tus nqi saib xyuas.

Warranty cov ntsiab lus kom paub meej:

• Duration- kev lag luam tus qauv 5 xyoo; zoo manufacturers muab 7-10 xyoo.
• Kev pab them nqi– suav nrog LED chips, tsav tsheb, fais fab mov, optics? Nws puas suav nrog kev ua haujlwm rau kev hloov pauv (lossis tsuas yog cov khoom seem hauv lub thawv)?
• Cov xwm txheej- Cov ntaub ntawv khaws cia txhua xyoo xav tau? Puas muaj kev puas tsuaj loj (yuav tsum hais meej meej tias yog)?
• Teb sijhawm- Muaj pes tsawg hnub ua haujlwm los hloov nkoj tom qab kev pom zoo tsis ua haujlwm?
• Lumen kev cog lus saib xyuas- L70 Ntau dua lossis sib npaug li 50,000 teev nrog TM-21 qhov projection qhia.

Kev lees paub lub sijhawm ua:

• Lub sij hawm ua qauv (tsis yog kev cai) - feem ntau 10-25 hnub.
• Kev cai optics lossis OEM brackets - 15-35 hnub.
• Puas yog qhov kev txiav txim maj nrawm rau kev rov ntxiv sai muaj?
• Koj puas khaws cov khoom lag luam hauv zos ntawm cov qauv sib txawv (tshwj xeeb tshaj yog rau cov neeg yuav khoom txawv teb chaws)?

Kev them nyiaj yug qhov project thiab teeb pom kev zoo layout Service

Vim li cas nws tseem ceeb:
Feem ntau cov neeg yuav khoom tsis tuaj yeem ua Dialux simulations lawv tus kheej. Seb cov chaw tsim khoom muab kev pab cuam tsim qauv ncaj qha txiav txim siab qhov project ua tiav.

Cov khoom siv yuav nug:

• Koj puas muabdawb pib teeb pom kev zoo simulation(raws li daim teb qhov ntev thiab lub hom phiaj chav kawm)?
• Koj puas tuaj yeem kho qhov teeb tsa raws li peb qhov chaw txwv (piv txwv li, txwv txoj haujlwm ncej)?
• Koj puas tuaj yeem muabteeb pom kev zoo layout drawings, luminaire lub sij hawm, thiab aiming lub kaum sab xis daim ntawv teev?
• Koj puas muab kev taw qhia ntawm qhov chaw lossis chaw taws teeb rau kev tsom thiab ntsuas?
• Rau tej yaam num loj, koj puas muab ibtemplate rau raws li-built illuminance ntsuas ntsuas?

Cov piv txwv tiag tiag los yog Cov Ntawv Thov Kev Sib Tham

School Sports Field

Case summary:
Ib lub tsev kawm ntawv theem nrab tau tsim ib qhov chaw tshiab 7-a-sab (65m × 45m) rau cov chav kawm PE, kev cob qhia pab pawg, thiab ob qhov kev sib tw hauv tsev kawm ntawv hauv ib xyoos. Cov peev nyiaj tsawg. Yam yuav tsum tau muaj: kev cob qhia yooj yim thiab teeb pom kev zoo qis qis, zam kev ua txhaum lub teeb rau cov tsev nyob ze.

Kev daws tau txais:

• Layout: sab layout (nrog ob sab ntev), 4 ncej, 12 m qhov siab.
• Luminaires: 4 × 300W LED dej nyab teeb rau ib tus ncej, tag nrho lub zog 4.8 kW.
• Kev faib tawm: symmetric 90℃beam, nrog anti-glare honeycomb visors.
• Tswj: yooj yim timer + phau ntawv dimming (kev cob qhia 50% lub zog, phim 100%).

Cov txiaj ntsig & tawm tswv yim:
Nruab nrab illuminance ~ 220 lx, U2=0.65, GR=32. Sab nraub qaum ntxiv ntxiv rau sab pem hauv ntej lub tsev - lub teeb txeej txo 70%. Cov kws qhia ntawv tau qhia txog kev txhim kho kev nyab xeeb rau yav tsaus ntuj kev cob qhia, cov nqi hluav taws xob tsuas yog 40% ntawm cov qub hlau halide system.

Cov yam ntxwv tsis sib xws (11-a-ib-ib sab tsev kawm kev cob qhia teb):

Community Field

Case summary:
Lub chaw ua si hauv zej zog muaj qhov loj 11-a-sab qhov chaw (105m × 68m, turf dag) rau cov neeg nyob hauv thiab cov koom haum nyiam. Xav tau kev sib tw amateur thiab qhib kev nkag mus rau txhua hnub, nrog rau kev txuag hluav taws xob thiab kev saib xyuas qhov tseem ceeb.

Kev daws tau txais:

• Layout: kaum layout, 4 ncej, 20 m qhov siab.
• Luminaires: 8 × 600W LED ib tus ncej, tag nrho lub zog 19.2 kW.
• Kev faib tawm: asymmetric duab plaub (30℃× 70 degree) kom npog tusyees ntawm touchline mus rau touchline.
• Tswj: ntse lub sij hawm-raws li dimming (19:00–21:00 tag nrho lub zog, 21:00–23:00 60%), tswj ntawm mobile APP.

Cov txiaj ntsig & tawm tswv yim:
Nruab nrab illuminance 350 lx (tag nrho lub zog), U2=0.72, GR=33. Kev tswj hwm hauv zej zog tau tshaj tawm cov nqi hluav taws xob txhua xyoo ~ $ 2,800, 62% txuag piv rau yav dhau los kev daws teeb meem. Lub sijhawm ua haujlwm txuas ntxiv mus txog 23:00, kev tsis txaus siab tau txo qis.

Hom parameter ntau yam (cov zej zog / amateur match field):

Multi-Lub hom phiaj sab nraum zoov

Case summary:
Lub chaw kab lis kev cai & kev ua kis las muaj ntau qhov chaw loj (110m × 70m) siv rau kev ncaws pob, rugby, kev ncaws pob, thiab kev ua yeeb yam. Teeb pom kev zoo yuav tsum hloov sai sai ntawm kev siv, nrog rau cov teebmeem dynamic rau kev ua yeeb yam.

Kev daws tau txais:

• Layout: hybrid (6 ncej – 4 ces kaum + 2 mid-side), qhov siab 25 m thiab 18 m.
• Luminaires: RGBW puv xim LED dej nyab teeb (5000K dawb rau hom kev ua si, xim rau hom kev ua haujlwm). Tag nrho 96 units - 64 dawb dimmable, 32 tag nrho-xim.
• Tswj: DMX512 + wireless chaw taws teeb, rau presets (kev cob qhia ncaws pob / ncaws pob / ncaws pob / kis las / kev ua haujlwm / xwm txheej).
• Kev tsim tshwj xeeb: rau hom kev ua tau zoo, ntxiv lub taub hau txav thiab strobes saum cov ncej, programmed nrog lub suab kaw lus.

Cov txiaj ntsig & tawm tswv yim:
Football hom: nruab nrab illuminance 500 lx, U2=0.68. Performance mode: chase, fade, strobe effects possible. Tus neeg teb xov tooj tawm tswv yim: ib daim teb tam sim no ua haujlwm rau kev ua kis las thiab kev ua yeeb yam, kev siv ob npaug; cov nyiaj tau los ntxiv daim pib them 30% ntawm tus nqi ntxiv rau cov xim luminaires.

Hom parameter ntau yam (multi-purpose teb):

Cov ntsiab lus:Txhua qhov xwm txheej xav tau kev daws teeb meem - cov tsev kawm tsom mus rau tus nqi thiab kev ua txhaum lub teeb, cov zej zog ntawm kev sib npaug thiab kev txuag hluav taws xob, cov chaw ua haujlwm tshaj lij ntawm kev ua tau zoo, thiab ntau lub hom phiaj ntawm kev hloov pauv. Tsis muaj teeb meem ntawm qhov xwm txheej, kev simulation kho qhov muag thaum ntxov thiab cov qauv sim ua kom txo qis tom qab rov ua haujlwm dua.

FAQ

1. Kuv daim teb yog 11-a-sab tab sis kuv muaj peev nyiaj tsawg. Kuv puas tuaj yeem nruab ib nrab lub teeb tam sim no thiab ntxiv tom qab?
Tsis pom zoo. Illumination yuav tsum ua tau raws li qhov yuav tsum tau ua nyob rau hauv ib qho kev teeb tsa ib zaug - kev teeb tsa theem tsim teeb pom kev loj / tsaus nti uas cuam tshuam nrog kev ua si ib txwm muaj. Yog tias pob nyiaj siv nruj, teeb tsa lub kaum sab xis nrog tsawg kawg ntawm cov luminaires kom tau raws li cov chav kawm kev cob qhia, tom qab ntawd hloov kho kom haum rau chav kawm los ntawm kev ntxiv cov luminaires (tsis hloov cov ncej).

2. LED lub neej ntawm 50,000 teev txhais li cas? Muaj pes tsawg xyoo nyob rau hauv kev xyaum?
50,000 teev yog hais txog L70 - sij hawm kom txog thaum luminous flux depreciates rau 70% ntawm thawj zaug. Thaum 4 teev ib hmo, 300 hmo hauv ib xyoos, uas yog 41 xyoo. Txawm li cas los xij, tus neeg tsav tsheb lub neej feem ntau luv dua (5-10 xyoo), yog li qhov tseeb tag nrho-luminaire hloov lub voj voog yog li 8-12 xyoo.

3. Puas yog qhov chaw ncaws pob teeb pom kev zoo xav tau kev tiv thaiv xob laim?
kiag li. Ncej feem ntau siab dua cov qauv nyob ib puag ncig thiab muaj kev cuam tshuam rau xob laim. Txhua tus ncej yuav tsum muaj nws tus kheej hauv av hauv av, nrog cov av tiv thaiv tsawg dua lossis sib npaug rau 10Ω (tsawg dua lossis sib npaug rau 4Ω hauv cov chaw taws teeb). Tsis tas li ntawd, cov luminaires yuav tsum muaj cov khoom siv tiv thaiv hluav taws xob (SPD Ntau dua lossis sib npaug ntawm 10kV).

4. Tom qab hloov mus rau LED, puas cov hlau halide cables uas twb muaj lawm yuav txaus?
Feem ntau yog, tab sis txheeb xyuas ob yam: ① LED tsav tsheb muaj qis qis-lub xeev tam sim no tab sis tej zaum yuav muaj luv luv inrush - xyuas tias cov khoom tawg tau sib xws; ② yog tias cov kab hluav taws xob uas twb muaj lawm yog nyias dhau thiab kev khiav ntev, qhov kev poob qis yuav ua rau muaj kev tiv thaiv hluav taws xob ntawm tus tsav tsheb LED. Qhov zoo tshaj plaws kom muaj tus kws kho hluav taws xob ntsuas qhov kawg ntawm kab hluav taws xob.

5. Vim li cas cov chaw tshaj tawm hauv TV yuav tsum muaj teeb pom kev ntsug?
Cov koob yees duab ntes qhov chaw ntsug - cov neeg ua si lub ntsej muag, lub tsho naj npawb, thiab lwm yam - tsis yog hauv av. Yog tias tsuas yog kab rov tav illuminance ua tau raws li lub hom phiaj tab sis ntsug illuminance qis dhau lawm, cov duab tshaj tawm qhia pom lub ntsej muag tsaus nti thiab cov keeb kwm yav dhau los. FIFA pom zoo kom illuminance ntsug ntawm tsawg kawg yog 1000-1500 lx nyob rau hauv lub ntsiab lub koob yees duab kev taw qhia.

6. Kuv puas tuaj yeem yuav cov luminaires kuv tus kheej thiab tom qab ntawd ntiav tus kws tshaj lij hluav taws xob los nruab lawv?
Technically yog, tab sis qhov kev pheej hmoo yog siab. Kev tsim teeb pom kev zoo xav tau kev sim kho qhov muag - random installation feem ntau ua rau thaj chaw tsaus lossis ci ntsa iab. Xav kom koj tsawg kawg kom tau txais daim duab kos duab thiab kos lub kaum sab xis ntawm cov chaw tsim khoom, tom qab ntawd kom tus kws kho hluav taws xob ua raws li daim duab kos thiab ua qhov ntsuas qhov pom kev tom qab kev teeb tsa.

7. Dab tsi yog "flicker-free"? Puas yog tag nrho LEDs flicker-dawb?
Tsis yog. Cov tsav tsheb tsis zoo LED tsim 100-120 Hz brightness ripple (flicker) uas tshwm sim raws li cov hlua khi ntawm cov koob yees duab ceev. Tsuas yog LEDs nrog cov tsav tsheb tas mus li tam sim no thiab tswj tau zoo ripple ua tau raws li cov kev xav tau hauv TV (flicker feem pua ​​​​tsawg dua lossis sib npaug li 1%). Thaum yuav khoom, nug meej meej tias nws yog "flicker-free" thiab nug rau daim ntawv xeem.

8. Kuv daim teb muaj qhov tsis sib xws (piv txwv li, nrog kev khiav khiav lossis hockey overlay). Kuv puas tuaj yeem qhia teeb pom kev rau txhua yam haujlwm?
Yog lawm. Ib qho hybrid layout thiab multi-angle optics tuaj yeem muab teeb pom kev zoo. Sau cov teeb pom kev zoo rau txhua qhov kev ua si thiab siv lub programmable dimming system los hloov scenes nrog ib lub pob. Peb pom zoo kom ntiav ib tus kws tsim teeb pom kev zoo los ua ntau txoj haujlwm simulations.

9. Lub luminaire warranty yog 5 xyoo, tab sis yuav ua li cas yog tias cov chaw tsim khoom tawm mus rau xyoo thib peb?
Xaiv lub hom lag luam nrog cov ntaub ntawv ua lag luam ntev - tsawg kawg 8 xyoo hauv kev ua haujlwm - thiab nug txog kev lav nyiaj hauv tuam txhab lossis lwm tus neeg txuas ntxiv warranty. Kuj nug cov chaw tsim khoom kom nthuav tawm cov npe ntawm cov neeg tsav tsheb thiab LED chips (xws li Philips, Osram). Txawm hais tias tus thawj chaw tsim tshuaj paus folds, generic spares yog yooj yim rau qhov chaw.

10. Dab tsi yog qee qhov kev kho sai rau qhov glare ntau dhau?
Yog tsis hloov luminaires, koj tuaj yeem: ① Ntxiv visors sab nraud (aluminium lossis stainless hlau, 20-30 cm dav); ② Tilt lub luminaires nqes 5℃-10℃ntxiv; ③ Txuas cov khoom siv tiv thaiv glare honeycomb louvres hla lub lens (qhov no yuav txo cov teeb pom kev zoo los ntawm 5% -10%). Yog hais tias glare tseem hnyav, koj yuav tsum tau hloov nrog zoo-optics luminaires.

Xaus thiab CTA

Saum toj no cov neeg siv yuav tsum ua tom ntej

Lub teeb pom kev ncaws pob tsis yog qhov yooj yim "yuav teeb thiab nruab lawv" qhov project. Los ntawm kev nkag siab cov qauv, kev npaj layout, xaiv luminaire, mus rau installation thiab commissioning, txhua kauj ruam cuam tshuam rau qhov kawg tshwm sim thiab cov nqi khiav hauj lwm mus sij hawm ntev. Ua raws li cov lus qhia no, koj tuaj yeem ua raws li hauv qab no:

1. Txhais koj cov kev xav tau- chav kawm teb (kev cob qhia / kev sib tw / TV tshaj tawm), qhov ntev, ib leeg lossis ntau lub hom phiaj.
2. Xyuas cov qauv- xa mus rau cov lej hauv zos thiab CIE / EN / GB rau illuminance, uniformity, glare, CRI, thiab lwm yam.
3. Xaiv qhov layout- kaum, sab, lossis hybrid; txiav txim siab ncej siab thiab txoj hauj lwm (nug manufacturers rau ib tug pre-simulation).
4. Xaiv cov luminaires txoj cai- tsis yog wattage xwb; tshawb xyuas kev ua tau zoo, faib nkhaus, IP ntsuas, ntawv pov thawj, IES cov ntaub ntawv.
5. Txiav txim siab tshiab vs. retrofit- ntsuam xyuas cov ncej thiab hluav taws xob uas twb muaj lawm, ua qhov sib piv nqi.
6. Thov kev txhawb nqa tsim- nug cov chaw tsim khoom rau Dialux simulation, layout drawing, aiming list.
7. Kev tsim khoom thiab kev kuaj xyuas zoo- siv daim ntawv ntsuam xyuas tus neeg muag khoom, kos npe rau daim ntawv cog lus nrog cov lus pom meej meej.
8. Professional installation thiab aiming- Tus kws kho hluav taws xob ua raws li kev kos duab, ntsuas qhov pom ntawm qhov chaw, qhov zoo ntawm cov kaum sab xis.
9. Kev saib xyuas tsis tu ncua- Cov lo ntsiab muag huv si, xyuas cov khoom tiv thaiv surge, sau cov lumen depreciation.

Muab layout pub dawb, Fixture Recommendation, lossis Project Consultation

Koj tsis tas yuav ua qhov no ib leeg.Raws li ib tug kws tshaj lij football teb teeb pom kev zoo daws teeb meem, peb muab cov kev pabcuam dawb hauv qab no (txawm tias koj thaum kawg yuav los ntawm peb):

• Dawb teeb pom kev zoo simulation (Dialux)- Xa peb koj daim teb qhov ntev, cov haujlwm ncej uas twb muaj lawm (yog tias muaj), thiab cov hom phiaj hauv chav kawm. Peb yuav muab daim ntawv qhia tsis tseeb-xim illuminance daim ntawv qhia, daim ntawv qhia kev sib xws, thiab cov npe pom zoo luminaire hauv 24 teev.
• Kev ntsuas rov qab pub dawb- Muab cov ncej qhov siab uas twb muaj lawm, cov duab, thiab cov qauv hlau halide tam sim no. Peb mam li ntsuam xyuas seb puas muaj peev xwm rov qab tau thiab muab kev kwv yees txuag hluav taws xob.
• Kev kuaj dawb dawb- Rau cov haujlwm loj, koj tuaj yeem thov ob lub teeb ci rau kev ntsuas ntawm qhov chaw (koj tsuas yog them tus nqi thauj khoom xwb).
• Kev pab tswv yim pub dawb- Peb cov kws tshaj lij tuaj yeem koom nrog lub rooj sib tham hauv chaw taws teeb los teb cov lus nug txog cov qauv, kev teeb tsa, kev tiv thaiv xob laim, kev tswj ntse, thiab lwm yam.



Peb lub Hoobkas & khoom siv



Ua txhua hmo ua si zoo li ci ntsa iab, nyab xeeb, thiab zoo siab ua ib hnub ua si.

Download Catalog

Thov Quote

Kev pab txhawb nqa

Ua tam sim no:
📧 Xa koj cov ntaub ntawv teb rau bwzm88@benweilighting.com
📞 Hu rau + 86 13007285242
