Cov khoom lag luam
PIR Sensor LED Txoj Kev Teeb pom kev zoo
Luminous Efficiency: 140lm / w, 160lm / w
LEDs: Philips Lumileds 3030
Cov tswv yim: AC 100-277V
Beam kaum sab xis: Hom II, Hom III, Hom IV, Hom V
Tsav tsheb hom: Sosen / Meanwell
0-10V, DALI, Microwave, Photocell, PIR sensor muaj
Khoom Taw Qhia:

Khoom feature:
BW LIGHT yog ib qho zoo tshaj plaws Led Street Lighting tuam ntxhab nyob hauv Suav teb. 2021 Private pwm tsim tshwj xeeb tsim,
5 Qhov ntau thiab tsawg pwm, muaj los ntawm 30-240w, Cov hluav taws xob hluav taws xob zoo heev, muaj peev xwm kho qhov muag thiab hluav taws xob.
Tuag-cam khwb cia txhuas lub cev nrog ntshiab polyester electrostatic tsuag, Hollow tshav kub dab dej tsim kom ntau airflow kom zoo dua tshav kub dissipation,
Imported Original Philips LEDs, nrog ntau dua lumen efficiency, txuag hluav taws xob thiab zoo illumination nyhuv.
CE RoHS Certificate, IP66 rated, Surge tiv thaiv 10KV / 20KV opitional, Zoo heev tshav kub tawg, optical thiab hluav taws xob muaj peev xwm,
Nrog 4/5mm super dawb toughened iav, Silicon roj hmab foob nplhaib, stainless screws.
Humanized tsim lub tswv yim, yooj yim rau nruab thiab tswj.
Khoom Specification:
| Qauv No | BW-A 30 | BW-A60 | BW-A100 | BW-A150 | BW-A 200 | BW-A 240 |
| Hwj chim | 30W | 60W | 100W | 150W | 200W | 240W |
| LED Hom | TIAB SA 3030 | |||||
| Lub teeb Efficiency | 130 lm/w, 1601 m/w | |||||
| Input voltage | AC 100-277V | |||||
| Tus tsav tsheb | Meanwell / Inventronics / SOSEN | |||||
| Kub dab dej | Tuag-cast aluminium vaj tsev | |||||
| Cov iav tiv thaiv | Tempered iav | |||||
| CRI | Ra 80 | |||||
| PF | >0.95 | |||||
| Hwj chim Efficiency | 90 feem pua | |||||
| Lens | Hom II, Hom ID, Hom IV, Hom V | |||||
| Lub teeb kub | 3000K /4000K / 5000K /5700K | |||||
| Sensor | Photocell / Microwave / PIR sensor rau kev xaiv | |||||
| Lub neej Span | 50000H (ntawm 25 degree ambient kub) | |||||
| Dimming | DALI/1-10V/PWM/FIVE DIMMING | |||||
| Kev ntsuas IP | IP66 | |||||
| Impact Resistance | ib 08 | |||||
| Surge Protecton | 10kV / 20kV rau kev xaiv | |||||
| Ua haujlwm kub | -30 degree - ntxiv rau 45 degree | |||||
| Qhov Loj (mm) | 398x195x77 | 521x220x76 | 521x270x76 | 578x270x76 | 643x330x77 | 643x330x77 |
Paub meej ntxiv:
LED Txoj Kev Teeb Dimension

Txoj kev teeb Bracket Instruction

LED Txoj Kev Teeb Paub meej
Led txoj kev teeb siv Lumileds SMD3030, Tag nrho lub teeb Luminous Efficiency txog li 140lm / w lossis 160lm / w,
Sosen / Meanwell Tsav Tsheb, Input Voltage AC100-277V
IP66 waterproof, haum rau qhov chaw ntub dej thiab sab nraum zoov daim ntaub ntawv, 5 xyoo warranty, tshaj 50, 000 teev

LED Txoj Kev Teeb Smooth tsim thiab Photocell
Niaj hnub nimno du tsim, tiv thaiv plua plav los ntawm kev cuam tshuam cov cua sov dissipation, precision tuag-casting molded thiab superior corrsion resistant hmoov
tus nqi ua tiav vaj tsev ua rau lub teeb ci no txhawb nqa kev tswj hwm thermal zoo dua thiab muaj peev xwm tu tus kheej.
Microwave, Photocell, PIR sensor rau kev xaiv

Kev teeb tsa:
